Figure 5F
CCGs in the facilitatory Presynaptic Delay model as stimulus direction and temporal frequency are varied.

CCGs are plotted for the connection EX_D 6_6_2 to DS 1_1 for drifting gratings at the antipreferred direction at TF = 1 and 10 Hz (red traces) and in the preferred direction at TF = 10 Hz (blue trace).

Model
Please get a Java compatible browser to see this.
Stimulus
Temporal frequency series, preferred and antipreferred directions Please get a Java compatible browser to see this.

Results

Data are presented in separate viewers for each DS unit, including spikes from all input EX and EX_D units, as well as the strongest weighted LGN/LGN_D and IN/IN_D units presynaptic to that DS cell.

Data for connections presynaptic to:
DS 0_0 DS 0_1 DS 1_0 DS 1_1
Please get a Java compatible browser to see this. Please get a Java compatible browser to see this. Please get a Java compatible browser to see this. Please get a Java compatible browser to see this.

Figure 5F
