Figure 4
The emergence of CCG features depends on the sign of the DS interaction and the direction of stimulus motion.

(A) Direction tuning curves for the facilitatory and suppressive Presynaptic Delay models.

(B) Direction tuning curves for the facilitatory and suppressive Postsynaptic Delay models.

(C) CCGs for EX_D-to-DS connections in facilitatory and suppressive Presynaptic Delay models with preferred and anti-preferred motion.

(D) CCGs for EX-to-DS connections in facilitatory and suppressive Postsynaptic Delay models with preferred and anti-preferred motion.

(E) Summary of all EX_D to DS CCG peak amplitudes in the facilitatory Presynaptic Delay model.

(F) Summary of all delayed EX to DS CCG peak amplitudes in the facilitatory Postsynaptic Delay model.

(G) Summary of all EX_D to DS CCG dip amplitudes in the suppressive Presynaptic Delay model.

(H) Summary of all delayed EX to DS CCG dip amplitudes in the suppressive Postsynaptic Delay model.
